規格mm | 二級 | 三級 | 自重 kg | 內水壓力 Mpa | ||
裂縫荷載 KN/m | 破壞荷載 KN/m | 裂縫荷載 KN/m | 破壞荷載 KN/m | |||
DN1500x150x2000 | 99 | 150 | 135 | 203 | 3886 | 0.1 |
DN1600x160x2000 | 106 | 159 | 144 | 216 | 4422 | 0.1 |
DN1600x160x2500 | 106 | 159 | 144 | 216 | 5527 | 0.1 |
DN1800x180x2000 | 120 | 180 | 162 | 243 | 5596 | 0.1 |
DN1800x180x2500 | 120 | 180 | 162 | 243 | 6995 | 0.1 |
DN2000x200x2000 | 134 | 200 | 181 | 272 | 6908 | 0.1 |
DN2000x200x2500 | 134 | 200 | 181 | 272 | 8635 | 0.1 |
DN2200x220x2000 | 145 | 220 | 199 | 299 | 8359 | 0.1 |
DN2200x220x2500 | 145 | 220 | 199 | 299 | 10449 | 0.1 |
DN2400x240x2000 | 152 | 230 | 217 | 326 | 9948 | 0.1 |
DN2400x240x2500 | 152 | 230 | 217 | 326 | 12435 | 0.1 |
DN2600x235x2500 | 172 | 260 | 235 | 353 | 13075 | 0.1 |
DN2800x280x2500 | 185 | 280 | 254 | 381 | 16925 | 0.1 |
DN3000x300x2000 | 198 | 300 | 273 | 410 | 15543 | 0.1 |
DN3200x290x2000 | 211 | 317 | 292 | 438 | 15890 | 0.1 |
DN3500x320x2000 | 231 | 347 | 321 | 482 | 19192 | 0.1 |
DN200x50x 2000 | 32 | 48 | 44 | 68 | 197 | 0.1 |
DN500x120x2000 | 81 | 120 | 107 | 161 | 1169 | 0.1 |
DN600x60x2000 | 40 | 60 | 53 | 80 | 622 | 0.1 |
DN600x120x3000 | 81 | 120 | 107 | 161 | 2035 | 0.1 |
DN1200x120x2000 | 81 | 120 | 107 | 161 | 2487 | 0.1 |
